CNC Horizontal Boring Machines
CNC Horizontal Boring Machines Manufacturer in Batala, Punjab, Find here CNC Horizontal Boring Machines dealer, suppliers, and exporters in India. just contact
| Boring spindle |
Spinder Diameter |
80mm |
100mm |
110mm |
| Taper |
ISO -40 With automatic clamping and Release
Of tools independent milling spindle |
ISO -50 With automatic clamping and Release
Of tools independent milling spindle |
ISO -50 With automatic clamping and Release
Of tools independent milling spindle |
| Traverses |
Cross of Traverse Table – X |
1100mm |
1300mm |
1500mm |
| vertical Traverse of hed stock- y |
1000mm |
1200mm |
1300mm |
| axial Traverse of boring spindle-z |
500mm |
550mm |
600mm |
| longitudinal of Traverse Table-w |
1500mm |
1600mm |
1700mm |
| Rotary work table |
Size ( standard ) |
1000x1000 |
1300x1300 |
1400x1400 |
| |
|
|
|
| T Slots |
Number |
5 |
6 |
6 |
| width |
19mm |
22mm |
22mm |
| permissible wight |
3000kgs |
4000kgs |
5000kgs |
| spindle speed ( continuous variation ) |
Boring spindle |
10-2000rpm |
10-2000rpm |
10-2000rpm |
| milling spindle |
2.5-250rpm |
2.5-250rpm |
2.5-250rpm |
| cnc system |
FANUC/SIEMENS |
FANUC/SIEMENS |
FANUC/SIEMENS |
| Feeds |
Continuous variation of speed at x,y,z,& w axis |
4-2000mm/min |
4-2000mm/min |
4-2000mm/min |
rapid feed rate at x, y, z, & w axis |
2000mm/min |
2000mm/min |
2000mm/min |
Continous variation of feed for table rotation |
0.001-1 rpm |
0.001-1 rpm |
0.001-1 rpm |
| Power |
main motor ( servo spindle motor ) |
11kw |
15kw |
20kw |
